Zeiss Otus 100mm f1.4 lens

Zeiss launches Otus 100mm f1.4 lens

 Zeiss has launched a 100mm f1.4 lens in its Otus range of lenses for Canon and Nikon full frame DSLRs. The Otus lens is completely manual focus and is designed to be used with the high resolution digital still and video cameras. Zeiss claims that this lens will be able to deliver medium format quality images.

Zeiss Otus 100mm f1.4

Zeiss talks about the high production quality which means that quality of each lens as well as consistency in the quality of all lenses will be maintained.

The f1.4 aperture will result in some outstanding separation between the subject and background and wonderful bokeh.

Zeiss Otus 100mm f1.4

According to Zeiss the Otus 100mm f1.4 lens will have minimal chromatic aberration and distortion due to the use of aspherical lens elements and special glass materials. The use of special T* reflecting coating is supposed to lead to extreme high contrast and minimal presence of stay light.

Zeiss Otus 100mm f1.4



The Zeiss Otus 100mm f1.4 with its full metal housing and high quality components is expected to give a smooth and precise focusing and operation of this lens. One can also safely put it to use in extreme environments.

The lens is priced at $4500 US Dollars.

Zeiss Otus 100mm f1.4 lens Data
Focal length 100 mm
Aperture range f/1.4 – f/16
Lens elements 14/11
Focusing range 1.0 m (39.37″) – ∞
Free working distance 0.83 m (32.68″) – ∞
Angular field*(diag. / horiz. / vert.) 24.1° / 20.2° / 13.6°
Diameter of image field 43 mm (1.69″)
Flange focal distance



ZF.2: 46.50 mm (1.83″)

ZE: 44.00 mm (1.73″)

Coverage at close range (MOD) 206 x 309 mm (8.11 x 12.17″)
Image ratio at MOD 1:8.6
Filter thread M86 x 1.00
Entrance pupil position ( in front of image plane) 35.0 mm (1.38”)
Rotation angle of focusing ring (inf – MOD) 315°
Diameter max.



ZF.2: 100.7 mm (3.96“)

ZE: 100.7 mm (3.96″)

Diameter of focusing ring



ZF.2: 90.0 mm (3.54″)

ZE: 90.0 mm (3.54″)

Length (without lens caps)



ZF.2: 126.5 mm (4.98″)

ZE: 128.8 mm (5.07″)

Length (with lens caps)



ZF.2: 150.1 mm (5.91 ″)

ZE: 152.3 mm (6.00″)

Weight



ZF.2: 1336 g (2.95 lbs)

ZE: 1405 g (3.10 lbs)

PRESS RELEASE

ZEISS Otus 1.4/100

New ZEISS Otus 1.4/100 DSLR Lens for the Most Demanding Applications

ZEISS adds a tele focal length to its line of lenses for full-frame DSLR cameras from Canon or Nikon

OBERKOCHEN/Germany, 2019-04-24.

With the ZEISS Otus 1.4/100, ZEISS is expanding its lens family for Canon1)– and Nikon1)-photographers who do not want to make any compromises concerning image and build quality. Whether in the studio or on-the-go, for portrait or product photography, the tele focal length delivers high resolution and outstanding definition in any situation – even at maximum aperture. This high-speed lens clearly sets the subject apart from the background. The exceptional level of detail and harmonic bokeh ensure the “3D pop effect”, ZEISS lenses are known for.

Achieving the outstanding image quality of medium format cameras

“The extremely high imaging performance and reliable production quality set the ZEISS Otus 1.4/100 apart in this class of lenses,” says Björn Pados, Product Manager for ZEISS Camera Lenses. “ZEISS’ comprehensive expertise and many years of experience went into developing the lens. The images captured with a ZEISS Otus lens in combination with a high-resolution, full-frame DSLR camera are on par with those created using a medium format system.”

The lens design, with aspheric lenses and special glass materials keeps chromatic aberrations and distortion to a minimum. Even when shooting against the light, the T* anti-reflective coating developed by ZEISS allows for extremely high contrast and minimizes stray light.

Zeiss Otus 100mm f1.4

Robust and reliable

The ZEISS Otus 1.4/100 also features impressive production quality and ergonomics: the extended rotation angle and smooth operation of mechanical components enable highly precise manual focusing. The stable full-metal housing with internal focusing ensures a consistent center of gravity and optimum balance when taking photographs. “This makes the ZEISS Otus 1.4/100 well-suited for the rough conditions a professional photographer faces, and its high-quality mechanical design ensures it will last for a long time,” adds Pados.

The ZEISS Otus lens series

The ZEISS Otus lens series was developed for professional photographers who expect unrestricted edge-to-edge image quality that extends across the entire aperture range. ZEISS launched its high-end SLR lens family back in 2013 with the release of the ZEISS Otus 1.4/55. This series continued with the addition of a short tele lens, the ZEISS Otus 1.4/85, in 2014. The ZEISS Otus 1.4/28 wide-angle lens followed in 2015.

Price and availability

Global delivery for the ZEISS Otus 1.4/100 will begin immediately, with a sales price of 4,500 Euros (incl. German VAT) or 4,500 US$ (excl. local taxes). A lens shade and protective caps for the front and back lenses are included.
